Show the full transaction state
Connect product selection, payment confirmation, dispensing and completion. Keep a paid order distinct from a confirmed dispense and provide clear guidance when the outcome is still unknown.
RK3568 VENDING CONTROL-SCREEN INTEGRATION
Connected Vending Applications
Bring selection, order progress and equipment feedback into an RK3568-based vending screen, with software and interfaces tailored to the selected machine.
Discuss Equipment Requirements
Application Highlights
RK3568-based vending control-screen software connecting product selection, machine status, dispensing and agreed payment or backend interfaces.
- RK3568 control-screen software
- Selection, order and dispensing feedback
- Machine and backend integration
This application illustrates software and integration scope, not a confirmed model or supply offer. RK3568 control-screen configuration, operating system and equipment interfaces are confirmed for the selected hardware and project.
Understand the application challenge
A vending screen must coordinate the customer journey with the machine controller and backend. Payment confirmation, dispensing feedback and order records can arrive at different times; the interface needs explicit pending, successful and failed states.
Adapt the screen to the machine controller
Map permitted dispensing commands, acknowledgements, stock information and faults. Align screen behaviour with the actual cabinet and peripheral interfaces.
Keep customer and service workflows consistent
Separate shopping from replenishment and diagnostics. Define access, order reconciliation and recovery when power or connectivity is interrupted.
Connect the equipment to the workflow
Use an RK3568-based upper-level screen for the customer and service interfaces. Connect documented machine commands, dispensing feedback and backend APIs around one agreed order-state model.
Review selection, pricing, checkout, dispensing, failed orders and replenishment. Agree which system owns payment, refunds, inventory and machine control.
Application context
Where the workflow takes shape
- Self-service retail selection and checkout
- Replenishment and service screens
- Connected vending operations
Integration focus
Define the system boundaries
- RK3568 board, display, touch and system-image adaptation
- Documented machine-controller commands and stock / fault events
- Payment-provider callbacks and order / inventory APIs where available
Expected Result
This is an illustrative application, not a completed customer project. The items below describe proposed outputs and checks to agree for an engagement; they are not reported project results.
Agreed deliverables
- RK3568 screen adaptation and application package
- Customer selection, order-progress and service interfaces
- Machine protocol and agreed payment / backend mappings
- Transaction verification records and deployment / handover instructions
Compatibility & acceptance checks
- Core platform
- RK3568; board, display and system image agreed for the machine
- Machine interface
- Controller command set, dispense feedback, stock and fault fields verified from documentation
- Payment boundary
- Provider, region, SDK / API and refund ownership agreed before integration
- Backend data
- Order identifiers, inventory updates and reconciliation rules mapped to available APIs
- Control responsibilities
- The designated machine controller manages actuators and protection; the screen sends permitted requests
- Acceptance
- Transaction-state consistency, failure handling, duplicate-event protection and restart recovery
Control screens in application
Control-screen software, equipment communication and system integration.
Interface and integration concepts. Actual screens and supported functions are defined for each project.
Vending control software
RK3568 software brings product selection, payment confirmation, dispense feedback into one operator interface. The screen is adapted to the selected hardware and workflow.
Vending control software
